Shaft Alignment and Geometric Measurements in New Package Solutions

Fixturlaser XA Pro

Fixturlaser XA Pro comes with an increased software and hardware package.

The software package contains all you need for performing shaft alignment of rotating machinery, e.g. horizontal and vertical shaft alignment, alignment of machine trains, Hot Check, and Softfoot. A new function is the “Machine Defined Data”, which makes it possible for the user to save machine configurations as templates. All machine data for each specific machine, such as machine dimensions, measurement distances, tolerances, and target values, are readily available in the Fixturlaser XA Pro alignment tool.

The hardware package for Fixturlaser XA Pro has also an increased content. Now it contains e.g. thin magnet brackets and an extension fixture, which are useful when working in narrow spaces. A magnetic base is also included which will facilitate the mounting of the measurement units on shafts with a big diameter.

Fixturlaser XA Ultimate

Fixturlaser XA Ultimate is a measurement tool with a complete software package for both shaft alignment and geometric measurements, such as flatness and straightness. Having a properly aligned machine starts already at the time of its installation, e.g. with checking if the machine foundation is skewed or warped in any way, which would influence the machine’s capability to work under optimal conditions. The Fixturlaser XA Ultimate tool gives the user access to all the software and hardware that is required for a successful machine installation and consequently ensuring optimal running conditions for the machine.
